170M1416 Eaton Bussmann Запобіжник
899 ₴
- Під замовлення
- Код: 170M1416
- +380 (67) 560-00-79
PRODUCT NAME
Eaton Bussmann series high speed square body fuse
CATALOG NUMBER
170M1416
UPC
051712216821
EAN
5027590440950
PRODUCT LENGTH/DEPTH
100 mm
PRODUCT HEIGHT
53 mm
PRODUCT WIDTH
21 mm
PRODUCT WEIGHT
134.5 g
WARRANTY
Not Applicable
COMPLIANCES
CE Marked
RoHS Compliant
CERTIFICATIONS
UL Recognized
IEC Rated
PRODUCT SPECIFICATIONS
TYPE
Fuse
APPLICATION
Semiconductor, DC Common bus, DC drives, power converters/rectifiers
AMPERAGE RATING
80 A
BREAKING CAPACITY
200 kA
FUSE INDICATOR
Top fuse status indicator
INSULATED METAL GRIPPING LUGS (IMGL)
No
UTILIZATION CATEGORY
aR (accompanied semiconductor protection)
VOLTAGE TYPE
AC
FUSE SIZE
000
RATED VOLTAGE AC
690 V
CENTER-TO-CENTER DISTANCE OF CONNECTIONS
78 mm
CURRENT TYPE
AC
MOUNTING DIMENSION
M8
CLASS
Class aR
CLEARING (I2T)
2550 at 660 V
WATT LOSSES
19 W
FUSE SHAPE
Square body, slotted offset bolted tags
PRE ARC (I2T)
380
COLOR
None
INTERRUPT RATING
200 kAIC
CONNECTION
Blade end x blade end
CONSTRUCTION SIZE
000
PACKAGING TYPE
Standard
VOLTAGE RATING
690 V (IEC), 700 V (UL)
Основні атрибути | |
---|---|
Виробник | Eaton |
- Ціна: 899 ₴
